- Servo-electric drive
- Welding force up to 50 N
- Weight approx. 1.5 kg
- Electrode stroke max. 10 mm
- Motor voltage 24 Vdc
- Excellent resetting performance
- Integrated displacement and force measurement
- Electric force adjustment
- Precise and fast positioning of electrodes
- Electrode holder water-cooled and secured against rotation
- Precise electrode quick-change system
- Integrated path measurement for component control, sinking depth, residual thickness
- Integrated force measurement
- Compact, flexible design with low dead weight
- High-precision applications with fast cycle times
- Welding of sensitive parts
- Thermocompression welding
- Micro welding
- In automated operation with high process reliability and reproducibility
- Sensor manufacturing: small, micro and nano range
